| NO |
Part No |
Description |
Reqd
No |
PRICE
|
NOTES |
| 93 |
94 |
| 1 |
24211-NF4-770 |
FORK R GEAR SHIFT |
1 |
1 |
¥2,080 |
- |
| 2 |
24221-NF4-770 |
FORK L GEAR SHIFT |
1 |
1 |
¥2,080 |
- |
| 3 |
24231-NF4-770 |
FORK C GEAR SHIFT |
1 |
1 |
¥2,080 |
- |
| 4 |
24265-KA3-760 |
SHAFT SHIFT FORK (M) |
1 |
1 |
¥580 |
- |
| 5 |
24266-KA3-760 |
SHAFT SHIFT FORK (C) |
1 |
- |
¥1,100 |
- |
| |
24266-NF4-900 |
SHAFT SHIFT FORK (C) |
- |
1 |
¥1,000 |
- |
| 6 |
24311-NF4-650 |
DRUM GERA SHIFT |
1 |
1 |
¥8,220 |
- |
| 7 |
24312-KA3-741 |
CENTER SHIFT DRUM |
1 |
1 |
¥1,750 |
- |
| 8 |
24315-HA0-000 |
PIN SHIFTER |
1 |
1 |
¥330 |
- |
| 9 |
24320-KS6-700 |
SHIFTER COMP DRUM |
1 |
1 |
¥1,500 |
- |
| 10 |
24322-HA0-000 |
COLLAR SHIFTER |
1 |
1 |
¥185 |
- |
| 11 |
24324-KA3-740 |
PAWL RATCHER |
2 |
2 |
¥350 |
- |
| 12 |
24326-360-010 |
PLUNGER PAWL |
2 |
2 |
¥240 |
- |
| 13 |
24328-KS6-700 |
PLATE GUIDE |
1 |
1 |
¥450 |
- |
| 14 |
24329-KA3-740 |
SPRING PAWL PLUNGER |
2 |
2 |
¥90 |
- |
| 15 |
24430-KA3-740 |
STOPPER COMP DRUM |
1 |
1 |
¥650 |
- |
| 16 |
24435-NF4-760 |
SPRING DRUM STOPPER |
1 |
1 |
¥160 |
- |
| 17 |
24610-KS6-700 |
SPINDLE COMP SHIFT |
1 |
- |
¥2,800 |
- |
| |
24610-NF4-900 |
SPINDLE COMP SHIFT |
- |
1 |
¥2,700 |
- |
| 18 |
24651-KV3-000 |
SPRING SHIFT RETURN |
1 |
1 |
¥220 |
- |
| 19 |
90022-MG8-000 |
PIVOT SHIFT DRUM STOPPER ARM |
1 |
1 |
¥135 |
- |
| 20 |
90435-HB3-000 |
WASHER 6.1mm |
1 |
1 |
¥105 |
- |
| 21 |
90451-155-000 |
WASHER 14mm |
1 |
1 |
¥130 |
- |
| 22 |
93300-06016-0A |
BOLT HEX 6*16 |
3 |
3 |
¥30 |
- |
| 23 |
94510-14000 |
CIRCLIP EXTERNAL 14mm |
1 |
1 |
¥30 |
- |
| 24 |
96220-40080 |
ROLLER 4*8 |
1 |
1 |
¥15 |
- |
|
