| NO |
PART NO |
DESCRIPTION |
01 |
02 |
PRICE |
REMARKS |
| 1 |
23211-NXA-000 |
SHAFT COMP., MAIN, PLAN-1 |
(1) |
(1) |
9,300 |
15T |
| |
23212-NXA-000 |
SHAFT COMP., MAIN, PLAN-2 |
1 |
1 |
9,300 |
14T |
| |
23214-NXA-000 |
SHAFT COMP., MAIN, PLAN-4 |
(1) |
(1) |
9,300 |
16T |
| 2 |
23221-NXA-610 |
COUNTERSHAFT |
- |
1 |
10,000 |
|
| |
23221-NX5-000 |
COUNTERSHAFT |
1 |
- |
10,000 |
|
| 3 |
23225-NX5-000 |
COLLAR, COUNTERSHAFT |
1 |
1 |
720 |
|
| 4 |
23411-NX5-000 |
GEAR, C-1ST, PLAN-1 |
(1) |
(1) |
9,900 |
35T |
| |
23412-NX5-000 |
GEAR, C-1ST, PLAN-2 |
1 |
1 |
9,900 |
31T |
| |
23413-NX5-000 |
GEAR, C-1ST, PLAN-3 |
(1) |
(1) |
9,900 |
30T |
| |
23414-NX5-000 |
GEAR, C-1ST, PLAN-4 |
(1) |
(1) |
9,900 |
33T |
| 5 |
23421-NX5-000 |
GEAR, M-2ST, PLAN-1 |
(1) |
(1) |
5,200 |
17T |
| |
23422-NX5-000 |
GEAR, M-2ST, PLAN-2 |
1 |
1 |
5,200 |
16T |
| |
23424-NX5-000 |
GEAR, M-2ST, PLAN-4 |
(1) |
(1) |
5,200 |
18T |
| 6 |
23431-NX5-000 |
GEAR, C-2ND, PLAN-1 |
(1) |
(1) |
9,900 |
32T |
| |
23432-NX5-000 |
GEAR, C-2ND, PLAN-2 |
(1) |
(1) |
9,900 |
29T |
| |
23433-NX5-000 |
GEAR, C-2ND, PLAN-3 |
1 |
1 |
9,900 |
28T |
| |
23434-NX5-000 |
GEAR, C-2ND, PLAN-4 |
(1) |
(1) |
9,900 |
31T |
| 7 |
23441-NX5-000 |
GEAR, M-3ND 4TH,, PLAN-1 |
(1) |
(1) |
12,900 |
17/19T |
| |
23442-NX5-000 |
GEAR, M-3ND 4TH,, PLAN-2 |
(1) |
(1) |
12,900 |
17/21T |
| |
23443-NX5-000 |
GEAR, M-3ND 4TH,, PLAN-3 |
(1) |
(1) |
12,900 |
17/24T |
| |
23444-NX5-000 |
GEAR, M-3ND 4TH,, PLAN-4 |
(1) |
(1) |
12,900 |
18/21T |
| |
23445-NX5-000 |
GEAR, M-3ND 4TH,, PLAN-5 |
1 |
1 |
12,900 |
18/24T |
| |
23446-NX5-000 |
GEAR, M-3ND 4TH,, PLAN-6 |
(1) |
(1) |
12,900 |
18/20T |
| 8 |
23461-NX5-000 |
GEAR, C-3RD, PLAN-1 |
(1) |
(1) |
9,800 |
27T |
| |
23462-NX5-000 |
GEAR, C-3RD, PLAN-2 |
1 |
1 |
9,800 |
27T |
| |
23463-NX5-000 |
GEAR, C-3RD, PLAN-3 |
(1) |
(1) |
9,800 |
26T |
| 9 |
23471-NX5-000 |
GEAR, C-4TH PLAN-1 |
(1) |
(1) |
9,800 |
26T |
| |
23472-NX5-000 |
GEAR, C-4TH PLAN-2 |
(1) |
(1) |
9,800 |
28T |
| |
23473-NX5-000 |
GEAR, C-4TH PLAN-3 |
1 |
1 |
9,800 |
31T |
| |
23474-NX5-000 |
GEAR, C-4TH PLAN-4 |
(1) |
(1) |
9,800 |
25T |
| 10 |
23481-NX5-000 |
GEAR, M-5TH, PLAN-1 |
(1) |
(1) |
7,500 |
22T |
| |
23503-NX5-000 |
GEAR, M-6TH, PLAN-3 |
1 |
1 |
7,500 |
21T |
| 11 |
23491-NX5-000 |
GEAR, C-5TH, PLAN-1 |
(1) |
(1) |
10,000 |
27T |
| |
23511-NX5-000 |
GEAR, C-6TH, PLAN-1 |
1 |
1 |
10,000 |
24T |
| 12 |
23495-NXA-000 |
COLLAR, 25*28*10.5 |
2 |
2 |
500 |
|
| 13 |
23501-NX5-000 |
GEAR, M-6TH, PLAN-1 |
(1) |
(1) |
7,500 |
20T |
| |
23502-NX5-000 |
GEAR, M-6TH, PLAN-2 |
(1) |
(1) |
7,500 |
23T |
| |
23503-NX5-000 |
GEAR, M-6TH, PLAN-3 |
(1) |
(1) |
7,500 |
21T |
| |
23504-NX5-000 |
GEAR, M-6TH, PLAN-4 |
(1) |
(1) |
7,500 |
26T |
| |
23505-NX5-000 |
GEAR, M-6TH, PLAN-5 |
(1) |
(1) |
7,500 |
24T |
| |
23506-NX5-000 |
GEAR, M-6TH, PLAN-6 |
1 |
1 |
7,500 |
22T |
| 14 |
23511-NX5-000 |
GEAR, C-6TH, PLAN-1 |
(1) |
(1) |
10,000 |
24T |
| |
23512-NX5-000 |
GEAR, C-6TH, PLAN-2 |
(1) |
(1) |
10,000 |
27T |
| |
23514-NX5-000 |
GEAR, C-6TH, PLAN-4 |
(1) |
(1) |
10,000 |
29T |
| |
23515-NX5-000 |
GEAR, C-6TH, PLAN-5 |
(1) |
(1) |
10,000 |
26T |
| |
23516-NX5-000 |
GEAR, C-6TH, PLAN-6 |
1 |
1 |
10,000 |
23T |
| 15 |
23512-KV3-770 |
COLLAR, SPLINE, 25*10.5 |
3 |
3 |
760 |
|
| 16 |
23802-NX5-770 |
SPROCKET, DRIVE, 15T |
(1) |
(1) |
3,700 |
|
| |
23803-NX5-770 |
SPROCKET, DRIVE, 16T |
1 |
1 |
3,800 |
|
| |
23804-NX5-770 |
SPROCKET, DRIVE, 17T |
(1) |
(1) |
3,900 |
|
| |
23805-NX5-770 |
SPROCKET, DRIVE, 18T |
(1) |
(1) |
4,000 |
|
| 17 |
90001-NXA-610 |
BOLT, FLANGE, UBS 10*45 |
- |
1 |
300 |
|
| |
90013-NXA-000 |
BOLT, FLANGE, UBS 12*28 |
1 |
- |
400 |
|
| 18 |
90402-PC6-000 |
WASHER, 12.5*35*5 |
1 |
- |
440 |
|
| |
90421-KAE-740 |
WASHER, 10mm |
- |
1 |
285 |
|
| 19 |
90451-KE8-000 |
WASHER, SPLINE, 25mm |
5 |
5 |
145 |
T1.5 |
| 20 |
90454-428-000 |
WASHER, THRUST, 20mm |
2 |
2 |
145 |
|
| 21 |
90461-286-000 |
WASHER, B, THRUST, 25mm |
2 |
2 |
195 |
T1.6 |
| 22 |
90462-323-000 |
WASHER, LOCK, 25mm |
2 |
2 |
150 |
T2.0 |
| 23 |
90601-107-000 |
CIRCLIP, 25mm |
6 |
6 |
135 |
|
| 24 |
91026-MN0-003 |
BEARING, NEEDLE, 20*24*11 |
1 |
1 |
570 |
|
| 25 |
91201-ML3-873 |
D-RING, 23.75 |
1 |
1 |
135 |
|
|
